• Industrial usage: false
• Managed: false
• Outdoorsuitable: false
• PoE (Power over Ethernet): false
• Protection against vanadlism: false
• VLAN: false
• IEEE Standard: IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX Fast Ethernet, IEEE 802.3ab 1000Base-T Gigabit Ethernet, IEEE 802.3x Flow Control and Back Pressure, IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3bt PoE++
• Switch Architecture: Back-plane (Switching Fabric): 10Gbps
• Data Processing: Store and Forward
• Flow Control: IEEE 802.3x Flow Control and Back Pressure
• Jumbo Frame: 9KB
• MAC address Table Size: 2K
• Packet Buffer Size: 1Mbits
• Network Connector: 5 x RJ-45 10/100/1000M auto negotiation, 1 x RJ-45 10/100/1000M with IEEE802.3bt In, 4 x RJ-45 10/100/1000M with IEEE802.3at Out
• Auto MDI/MDI-X function, Full/Half duplex
• Network Cable: UTP/STP Cat.5e or above Cable, EIA/TIA-568 (100m)
• Protocol; CSMA/CD
• LED:bt (Green):ON?PoE IEEE 802.3bt is detected, OFF?PoE IEEE 802.3bt is not detected, PWR (Amber):, ON?Power is detected, OFF?Power is not detected, PoE (Amber): ON?PSE is activated and PD is detected
• LNK/ACT (Green):ON?TX port is detected, Flashing?TX data is transmitting/receiving
• Reserve polarity protection: Present
• Overload current protection: Present
• Power Consumption: 3.9W without PoE load
• PD power input: 30W/60W/90W
• PoE Power: Maximum total PSE power output 60W
• Operating Temperature: -40°C to 75°C
• Operating Humidity: 5% to 95% (Non-condensing)
• Storage Temperature: -40°C to 85°C
• Housing: Rugged Metal, IP30
• Case Dimension (L x W x D): 103.5 x 32 x 81.5 mm
• Installation mounting: DIN Rail Mount or Wall Mount
