• Installation: Rack
• Plug: IEC 60320 C14 inlet
• Power: 1500VA – 3000VA
• Inch form factor (IEC 60297): 482.6 mm (19")
• The battery module can be installed in a 19” rack or as a separate tower with stand
• Hot swappable – Batteries can be exchanged during operation
• Compatible with OnLine UPS: DN-170096
• Battery voltage: ±82,5 VDC
• Capacity (standard unit): 12 V / 9 Ah
• Number of installed rechargeable batteries: 12 units
• Batteries in a row: 6 (per battery module)
• Battery type: Lead battery
• Typical charging time: 12 hours to recover 90% of full capacity
• Operating temperature: 20 °C to +25 °C
• Humidity during operation: 0 - 90%
• Terminal connections on the back
• Dimensions (L×W×D): 86,5 x 440 mm x 710 mm
• Net weight: 41,1 kg
• Gross weight: 44,2 kg
• Weight of the individual lead-acid batteries: 2.7kg
• Weight of the individual battery modules: 38.5kg
• Total weight of the lead-acid battery: 32.4kg
