Allows control and monitoring of multiple UPS units through RJ45 network connection
Real-time dynamic graphs of UPS data (voltage, frequency, load level, battery level)
Warning notifications via audible alarm, broadcast, mobile messenger, e-Mail and SNMP traps
Historic data log stored in centralized PC database
Password security protection and remote access management
Interface: High-speed asynchronous RS232 serial interface for communication with UPS
Network Protocol: TCP/IP, UDP, SNMP, SSL, Telnet, HTTP, SMTP, DHCP, DNS, etc.
LED indicators: Power, Status, Run, LAN 10/100M Link/Active
CPU: ARM 300MHz 32-bit
SDRAM: 64M Byte SDRAM
Flash: 128M Byte NAND Flash
LAN Port: 10/100M UTP
Input Power (DC): 8-15V
Power Consumption: Max. 3W
Dimension (DxWxH) mm: 81x 52x 26
