Assortment: DisplayPort Cables
AWG: 28
Color cable: black
Color connector: black
Connector 1: DP, plug
Connector 2: DVI-I, (24+5), jack
Connector surface: nickel-plated
DisplayPort standard: DisplayPort 1.1a
Ferrite filter: none
HDTV Standard: Full HD
Hoods: molded
Interlock: Snap fastener
Packaging: Polybag
Wire material: CU
Length: 0.15 m
AOC - Active Optical Cable: false
Shielding: Double shielding
Support up to 1080p with 60Hz
Supports digital full HD and a higher transmission rate by Single Link.
Copper wire, foil and braid shielding for robustness and reliable connection
Plug and play, no additional driver needed
Attention! The DVI socket supports the connection of 24+5 plugs, but only transmits single link 18+1 DVI-D signals in Full HD resolution.
Supports DisplayPort 1.1
Bandwidth: 6.75 (2.25 per channel, 225 MHz)
Color depth: 36bit (12bit per channel)
Power supply via DisplayPort
Input: DisplayPort male connector, 20 pin
Output: DVI female connector, (24+5)
Resolutions: 480i, 576i, 1080i, 480p, 576p, 720p, 1080p (50 / 60 Hz)
Operating temperature: 0°C to +45°C
Operating humidity: 10% to 80% RH (no condensation)
Storage temperature: -10°C to +80°C
Storage humidity: 5% to 90% RH (no condensation)
Power consumption: 300 mW
Entire cable length: 15 cm
Color: black
