Number of ports: 4
PoE Power budget: 100 W
PoE standard: IEEE802.3at (PoE+)
Ethernet speed: Gigabit
Industrial usage: true
Managed: false
Number of ports (Uplink): 1
Outdoorsuitable: false
PoE (Power over Ethernet): true
Protection against vanadlism: false
Uplink port connection: SFP
VLAN: false
4 ports 10/100/1000 Base-Tx RJ45 with autonegotiation and Auto-MDI/ MDI-X function, PoE IEEE 802.3af/at (up to 30W)
1-port 1000Base-Fx interface SFP
48V to 57V DC, redundant power connection possible
Operating temperature: - 40? to 80?
IP40 aluminum housing
Supports 6KV DC Ethernet ESD protection
Supports 6KV DC EFT protection for the power line
Vibration, shock and drop protection
Performance specification: Bandwidth: 14Gbps, Packet buffer memory: 1.2Mbit, Packet forwarding rate: 10.5Mpps, MAC address table: 2K
Flow control: utilizes backpressure technology for half-duplex, utilizes "pause frame" technology in full-duplex mode
Housing: aluminum housing with protection class IP40
LED display: Power: Red, Fiber: Link 2(Green), Ethernet: Yellow
Power input: 48 to 57V DC, it is possible to install a redundant power supply
Power consumption: < 3 watts
Network protocols: IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u;100Base-TX/FX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x
Industry standard: FCC CFR47 Part 15, EN55022/CISPR22, Class A, IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air), IEC61000-4-3 (RS): 10V/m (80~1000MHz), IEC61000-4-4 (EFT): power connection: ±4kV; data connection: ±2kV, IEC61000-4-5 (overvoltage)
Dimensions (W x D x H): 118 x 92.4 x 40 mm
Product weight: 0.55 kg
Working environment: Operating temperature: -40 to max 80?; Storage temperature: -40 to max 80?
Relative humidity: 5% to max. 95% (no condensation)
Total PoE power budget (W): 100 W
