Number of ports: 8
PoE Power budget: 80 W
PoE standard: IEEE802.3at (PoE+)
Ethernet speed: Gigabit
Industrial usage: false
Installation type: 10 inch, Desktop
Managed: true
Outdoorsuitable: false
PoE (Power over Ethernet): true
Protection against vanadlism: false
VLAN: true
Number of PoE ports: 8 x 10/100/1000Base-TX RJ45
Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x full-duplex flow control, IEEE802.3ab link aggregation
PoE standards: IEEE802.3af, IEEE802.3at
Forwarding rate: 10/100/1000Mbps
LED displays: Power, Link/Act
Backplane bandwidth: 16G
Forwarding capacity: 11.9 Mpps
Jumbo frame size: 16 K
MAC addresses: 8K
Package buffer storage: 4.1 Mbit
RAM for CPU: 1 Gbit / Flash memory: 128 Mbit
PoE total budget: 80 watt output 802.3at (PoE+ support)
PoE budget per port: 30 watt max.
PoE voltage: 52 V
PoE PIN assignment: V- (RJ45 Pin1, 2), V+ (RJ45 Pin 3,6) Mode A, Endspan
PoE Management: PoE status and control, PoE schedule, PD alive auto check
Port features: Port Control, Port Isolation, Port Loop Detection
Port mirroring: Multi to 1 Sniffer
VLAN: Port-based & 802.1q Tag-based VLANs
Link aggregation: 8 groups
Rate limit: 64kbps
Spanning tree: Supports STP, RSTP, MSTP
Ring protocol: Supports EAPS
Multicast: Supports 256 multicast groups & IGMP snooping for multimedia applications
Supports Static ARP & Static Routing, up to 32 VLAN interfaces
QoS: 4 lines per port, scheduling algorithm: WRR, SP, WFQ, port-based, MAC-based, 802.1p, DSCP classification
ACL: Standard IP, Extend IP, MAC IP, ARP, 512 entries
Security: MAC-based authentication, AAA/RADIUS authentication, WEB/Telnet password protection, Accessing privilege mode password protection
Supports SMNP
Supports ICMPv6, IPv6 Neighbor Discovery, MLD Snooping, IPv6 Telnet
Management interfaces: WEB, SNMP, SSH, CLI, Telnet, TACACS+, RMON
L3-VLAN Interface: 32
Operating voltage: 100 - 240 V AC, 50/60 Hz, integrated power adapter (IEC C13 plug for non-heating appliances)
Power suppy: 96 W max.
Operating temperature: 0 °C to 40 °C
Storage temperature: -10 °C to +70 °C
Operating humidity: 5% - 95% (non condensing)
Housing: Metal (with protective conductor terminal)
Dimensions: W 250 x D 150 x H 44 mm
Weight: 1.140 kg (without packaging)
