• Number of ports: 8
• Ethernet speed: Fast Ethernet
• Industrial usage: true
• Installation type: DIN rail
• Managed: false
• Number of ports (Uplink): 1
• Outdoorsuitable: false
• PoE (Power over Ethernet): false
• Protection against vanadlism: false
• Uplink port connection: SFP
• VLAN: false
• 8 ports 10/100 Base-Tx RJ45 with auto-negotiation and Auto-MDI/ MDI-X function
• 1-port 100Base-Fx interface SFP
• 12V to 48V DC, redundant power connection possible
• Operating temperature: - 40? to 80?
• IP40 aluminum housing
• Supports 6KV DC Ethernet ESD protection
• Supports 6KV DC EFT protection for the power line
• Vibration, shock and drop protection
• Performance specification: Bandwidth: 1.8Gbps, Packet buffer memory: 1.25Mbit, Packet forwarding rate: 1.4Mpps, MAC address table: 2K
• Flow control: utilizes backpressure technology for half-duplex, utilizes "pause frame" technology in full-duplex mode
• Housing: aluminum housing with protection class IP40
• LED display: Power: Red, Fiber: Link 2(Green), Ethernet: Yellow
• Power input: 12 to 48V DC, it is possible to install a redundant power supply
• Power consumption: <8 watts
• Network protocols: IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u;100Base-TX/FX;
• Industry standard: FCC CFR47 Part 15, EN55022/CISPR22, Class A, IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air), IEC61000-4-3 (RS): 10V/m (80~1000MHz), IEC61000-4-4 (EFT): power connection: ±4kV; data connection: ±2kV, IEC61000-4-5 (overvoltage)
• Dimensions (W x D x H): 142.5 x 107.1 x 53.5 mm
• Weight: Product weight: 0.65kg
• Working environment: Operating temperature: -40 to max 80?; Storage temperature: -40 to max 80?
• Relative humidity: 5% to max. 95% (no condensation)
